FSM330~FSM340P72 (330W/335W/340W) Typical 72 Cells Poly Crystalline
Solar PV Module
Electrical Characteristics under STC (STC: Irradiance 1000W/㎡, Cell Temperature 25℃, Air Mass 1.5)
| Module Type | FSM330P72 | FSM335P72 | FSM340P72 |
| Maximum Power-Pmax (Wp) | 330 | 335 | 340 |
| Voltage at Maximum Power-Vmp (V) | 37.7 | 37.9 | 38.1 |
| Current at Maximum Power-Imp (A) | 8.75 | 8.86 | 8.92 |
| Open Circuit Voltage-Voc (V) | 46.3 | 46.5 | 46.6 |
| Short Circuit Voltage-Isc (A) | 9.45 | 9.55 | 9.64 |
| Module Efficiency-ηm (%) | 17.0% | 17.3% | 17.5% |
| Operating Temperature | -40℃ to +85℃ |
| Maximum System Voltage | 1000V/1500V DC (IEC) |
| Power Tolerance | 0~+3% |
| Temperature Coefficients of Pmax | -0.40%/℃ |
| Temperature Coefficients of Voc | -0.31%/℃ |
| Temperature Coefficients of Isc | 0.04%/℃ |
Mechanical Characteristics
| Cell Type | Poly Crystalline 157×157mm |
| No. of Cells | 72 (6×12) |
| Dimension | 1956×992×35mm |
| Weight | 20.5 Kg |
| Junction Box | IP68, 3*20A diodes |
| Output Cables | 4.0mm², 1100mm Length (Optional) |
| Connectors | MC4 compatible (Optional) |
| Packing | 31PCS/Pallet, 748PCS/40’HC |
Key Features
- Typical 72 full cells series connection with standard dimension and
low weight available to chare 24/48V DC solar system.
- Anti-reflective coating glass to increase module efficiency up to
2% and improvement of self clean ability.
- High efficiency Poly Crystalline Solar Cell to guarantee higher
output power and higher module efficiency (up to 17.5%).
- Excellent Anti-PID performance guarantee limited power degradation
for mass production.
- Certified to withstand: front side max. 5400Pa, rear side max.
2400Pa.
- IP68 rated junction box with high quality diodes available for
1500V AC system voltage.
- MC4 compatiable connectors for solar system easy installation.
- Three times EL inspections and power test before packing.
- Automatic production and QC detections from advanced equipment and
production lines following with IEC61215 and IEC61730 standards.
- MES system applied together with production line to ensure products
information searchable and traceable.
- 15 years product workmanship warranty, 12 years power output no
less than 90% and 30 years power output no less than 80%.
About FINERGY
1. FINERGY only sources raw materials from Tier1 suppliers which
passed the strict tests in our own factory laboratory. We have to
provide dependable quality products to customers as well as
reliable long period warranties.
2. FINERGY has accumulated rich experience of solar panels
manufacturing. We also cooperates with design and research
institutes to study and develop new technology adopted on solar
panels for efficiency improvement.
3. FINERGY made large investments on automatic equipment and
production lines since 2016. The advanced quality inspection
facilities are combined with production lines together. Besides
this, MES system was applied online to manage and record products
data information. It's available for us to save waste and improve
production capacity.
4. FINERGY has 6 production lines in factory now. The annual
production capacity has reached 800MW now. Hundreds MW of solar
panels are produced and shipped from us every year. The proven
products have been installed in more than 40 countries all over the
world.
5. FINERGY already set up sales networks in Asia, Middle East,
Europe and South America. The customers can benefit from our
collaborations depending on higher quality, price/ performance
ratio.
Production Workshop
1.1MW Project Reference with FSM330P72
